Violaceae

 8-Flower in l.s., closer view

[FMP-field: image]
This is the same flower as in the previous image, but at a higher magnification to show the details of the anthers and nectar glands. Also note the parietal placentation of the ovules within the ovary.
Photo taken by K. R. Robertson and D. L. Nickrent of plants cultivated at the University of Illinois.
